We have added 2 new 620kv, 40mm stator multi-rotor motors to our store getfpv.com and they are both in stock and ready to ship.

1.) Updated NX-4008 620kv

An updated version of the popular NX-4008 in all black and with long motor cables. Still with the triangular mounting hole pattern. Bolts right onto the Pro Tricopter Delrin Kit.

• KV: 620kv
• Weight (with cables): 87g
• Suitable Props: 9, 10, 11, 12 x 4.5, 4.7, 5
• Most Efficient Prop Size: 10×4.7 or 10×5
• ESC: 18amp or higher
• Lipo: 3s or 4s
• Cable Length: 320mm
• Cable Gauge: 20AWG
• Stator: 40mm
• Diameter: 45mm
• Mounting Holes: 2 sets of 3 Triangularly positioned holes. Large triangle: each triangle side is 27.3mm. Small triangle: each triangle side is 13mm.
• Suitable Mounting Screw: 6mm M2.5 (for QAV500), 20mm M2.5 (for Pro Tricopter Kit). Button-head, socket screw, or phillips head.
• M2.5 mounting screws/hardware not included.

Buy Here

Videos flown with the NX-4008 on a tricopter with 4s Lipo and 10″ APC props

On-board recording (pilot: timnilson)

Looking at a tricopter (pilot: Kevinv033)

2.) A new 40mm stator motor called the FM-4008

This motor also has long motor cables. It also features a thicker 4mm shaft compared to the 3mm shaft of the NX-4008. The motor comes with 2 aluminum shaft rings to get the shaft to be 5mm or 6mm in diameter. This beefed up NX-4008 also does not use a prop adapter or integrated prop saver anymore. Instead, this motor uses a threaded steel shaft with an aluminum spinner. This motor has mounting holes that are 25x25mm apart. This pattern is supported by the QAV500 FPV Quadcopter frame. You will not be able to mount this motor onto the Pro Tricopter Delrin Kit.

Buy Here

• KV: 620kv
• Weight (with cables): 99g
• Suitable Props: 9, 10, 11, 12 x 4.5, 4.7, 5
• Most Efficient Prop Size: 10×4.7 or 10×5
• ESC: 18amp or higher
• Lipo: 3s or 4s
• Cable Length: 320mm
• Cable Gauge: 20AWG
• Stator: 40mm
• Diameter: 45mm
• Mounting Holes: 25mm x 25mm across
• Suitable Mounting Screw: 6mm M3 button-head or socket screw
• M3 mounting screws/hardware not included.

Flown with the FM-4008 on the QAV500, 4s Lipo, and 10″ Graupner E-Props

Specs

Both motors have the same 40mm stator and 45mm total diameter. They are also wound identically and will produce similar thrust.
